DNV GL 240V AC 50Hz Molas NL Lidar Wind Speed Measurement

Name: DNV GL 240V AC 50Hz Molas NL Lidar Wind Speed Measurement
Brand: MOVELASER
SKU: Molas NL
Price: 5 USD
Availability: InStock
Rating: 4.5 (148 reviews)

Large Image : DNV GL 240V AC 50Hz Molas NL Lidar Wind Speed Measurement

Product Details:

Place of Origin:	China
Brand Name:	MOVELASER
Certification:	DNV GL , Intertek , RISO Dtu
Model Number:	Molas NL

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Dollar 5W$+ （Price consultation customer service）
Packaging Details:	Air Box
Delivery Time:	1-2 months
Payment Terms:	L/C, D/A, D/P, T/T
Supply Ability:	200 set ，1 month

Contact Now

Detailed Product Description

Measure The Distance:	50~200m	Number Of Measured Sections:	10
Sampling Frequency:	4Hz	Wind Speed Measurement Range:	-50 ~50m/s
Wind Direction Measurement Range:	-180°～180°	Accuracy Of Wind Direction:	±0.5°
Communication Mode:	Profibus DP/Modbus TCP/ Modbus RTU/CANOPEN	Power:	≤300W
Operating Temperature Range:	-40℃～60℃	Survival Temperature Range:	-40 ℃ ~ 65 ℃ (power Off),-45 ℃ ~ 65 ℃ (charged)
Working Humidity Range:	0～100% RH	Survival Wind Speed:	70m/s
Working Acceleration Range:	-0.5g～0.5g	IP Protection Level:	Equipment In Engine Room: IP54,Equipment Outside Engine Room: IP66
Anticorrosive:	ISO C5	Radiation Protection:	CISPR 11
Weight:	OHabout23Kg,DUabout6Kg
High Light:	50Hz Molas NL Lidar , 240V AC Molas NL Lidar , DNV GL lidar wind speed measurement

Working Voltage And Frequency 240VAC 50Hz

1,Summary

The anti-fall rope is mounted on the OH ring by a bow shackle, and the other end is mounted on the lidar mount or the anchor point outside the fan cabin, as shown in the following figure.

2,Performance Parameter

Performance
Measure the distance	50~200m
Number of measured sections	10
Sampling frequency	4Hz
Wind speed measurement range	-50 ~50m/s
Wind direction measurement range	-180°～180°
Wind speed accuracy	0.1m/s
Accuracy of wind direction	±0.5°
Beam pointing accuracy	±0.1°

Other
Communication mode	Profibus DP/Modbus TCP/ Modbus RTU/CANOPEN
Power supply	100 VAC~240VAC ±10% 50Hz~60Hz ±6%
Power	≤300W
Operating temperature range	-40℃～60℃
Survival temperature range	-40 ℃ ~ 65 ℃ (power off),-45 ℃ ~ 65 ℃ (charged)
Working humidity range	0～100% RH
Survival wind speed	70m/s
Working acceleration range	-0.5g～0.5g
IP protection level	Equipment in engine room: IP54,Equipment outside engine room: IP66
Anticorrosive	ISO C5
Radiation protection	CISPR 11
Weight	OH约23Kg,DU约6Kg

DNV GL 240V AC 50Hz Molas NL Lidar Wind Speed Measurement 0
