IP65 IP66 Nacelle Wind Lidar System Movelaser Wind Measurement Lidar

Large Image : IP65 IP66 Nacelle Wind Lidar System Movelaser Wind Measurement Lidar

Product Details:

Place of Origin:	China
Brand Name:	MOVELASER
Certification:	DNV GL , Intertek , RISO Dtu
Model Number:	Molas NL

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Dollar 5W$+ （Price consultation customer service）
Packaging Details:	Air Box
Delivery Time:	1-2 months
Payment Terms:	L/C, D/A, D/P, T/T
Supply Ability:	200 set ，1 month

Contact Now

Detailed Product Description

Measure The Distance:	50~200m	Number Of Measured Sections:	10
Sampling Frequency:	4Hz	Wind Speed Measurement Range:	-50 ~50m/s
Beam Pointing Accuracy:	±0.1°	Communication Mode:	Profibus DP/Modbus TCP/ Modbus RTU/CANOPEN
Survival Temperature Range:	-40 ℃ ~ 65 ℃ (power Off),-45 ℃ ~ 65 ℃ (charged)	Working Humidity Range:	0～100% RH
Survival Wind Speed:	70m/s	Working Acceleration Range:	-0.5g～0.5g
IP Protection Level:	Equipment In Engine Room: IP54,Equipment Outside Engine Room: IP66	Anticorrosive:	ISO C5
Radiation Protection:	CISPR 11
Highlight:	IP65 IP66 Nacelle Wind Lidar , Nacelle Wind Lidar System , Movelaser Wind Measurement Lidar

Equipment In The Nacelle:IP65 Equipment Outside The Nacelle:IP66

1,Summary

After the previous step, the left blank list will display the tempered wind speed data, you can select the required data freely, or check the “Download Settings” section “Download All” to select all.

2,Performance Parameter

Performance
Measure the distance	50~200m
Number of measured sections	10
Sampling frequency	4Hz
Wind speed measurement range	-50 ~50m/s
Wind direction measurement range	-180°～180°
Wind speed accuracy	0.1m/s
Accuracy of wind direction	±0.5°
Beam pointing accuracy	±0.1°

Other
Communication mode	Profibus DP/Modbus TCP/ Modbus RTU/CANOPEN
Power supply	100 VAC~240VAC ±10% 50Hz~60Hz ±6%
Power	≤300W
Operating temperature range	-40℃～60℃
Survival temperature range	-40 ℃ ~ 65 ℃ (power off),-45 ℃ ~ 65 ℃ (charged)
Working humidity range	0～100% RH
Survival wind speed	70m/s
Working acceleration range	-0.5g～0.5g
IP protection level	Equipment in engine room: IP54,Equipment outside engine room: IP66
Anticorrosive	ISO C5
Radiation protection	CISPR 11
Weight	OH约23Kg,DU约6Kg

IP65 IP66 Nacelle Wind Lidar System Movelaser Wind Measurement Lidar 0
