MOVELASER Switch Button Nacelle Lidar 1Hz Sampling Rate

Name: MOVELASER Switch Button Nacelle Lidar 1Hz Sampling Rate
Brand: Nanjing Movelaser Co., Ltd.
SKU: Molas B300
Price: 6 USD
Availability: InStock

Brand Name:	MOVELASER
Model Number:	Molas B300
MOQ:	1 set
Price:	Dollar 6W$+ （Price consultation customer service）
Delivery Time:	1-2 months
Payment Terms:	L/C, D/A, D/P, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

WINDGUARD / RISO Dtu / DNV GL / Intertek

Sampling Rate:

1Hz

Wind Direction Measurement Accuracy:

1°

Wind Direction Measurement Range:

0~360°

Sweep Cone Angle:

28°

Range Of Working Temperature:

-40℃ ~ 50℃

Operating Humidity Range:

0% To 100%

Eye Safety:

Class 1M (EN60825-1)

Packaging Details:

Air Box

Supply Ability:

200 set ，1 month

Highlight:

Switch Button Nacelle Lidar

Nacelle Lidar 1Hz Sampling Rate

MOVELASER nacelle based lidar

Product Description

Switch button press it to run the device

1,Product introduction

Switch button, press it to run the device. The switch on the indicator light can display the status of the lidar. In the running state, the indicator flashes and the device is normal, and the indicator light is always on and the lidar is in a fault state.

The four core modules of Molas B300 series are independently designed from fiber laser radar transmitter, laser transceiver system, high-speed data acquisition system, and high-precision data processing software. Each core module has a high degree of matching, which ensures the unified coordination and Data and information security has reached the international advanced level.

2,Product parameters

**General parameters**
Powered by	24V DC / 100~240V
Power	70W
Size	520420550mm
Weight	<50kg
Range of working temperature	-40℃ ~ 50℃
Operating humidity range	0% to 100%
Protection class	IP65 (core module) / IP54 (complete machine)
Eye safety	Class 1M (EN60825-1)

**Measurement parameters**
Measuring distance	30~300m
Measurement layer	12
Sampling rate	1Hz
Wind speed measurement accuracy	0.1m/s
Wind direction measurement accuracy	1°
Wind speed measurement range	0~75m/s
Wind direction measurement range	0~360°
Sweep cone angle	28°

3,Application field

Wind resource assessment / Micro site selection and review / Wind power prediction system

Wind farm / wind farm performance evaluation / Weather detection
