Product Details:
Place of Origin: China
Brand Name: MOVELASER
Model Number: Molas 3D
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Dollar 13W$+ (Price consultation customer service)
Packaging Details: Air Box
Delivery Time: 1-2 months
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 200 set ,1 month
Detailed Product Description
Line-of-sight Detection Distance: 6km/3km Distance Resolution: 30m, 75m
Blind Spot Width: 50m/100m Accumulation Time: 0.5s/1s/2s/4s/8s Optional
Radial Wind Speed Measurement Range: -75~+75m/s Radial Wind Speed Measurement Accuracy: 0.1m/s
Number Of Distance Gates: 300 Laser Safety Level: IEC 60825-1 (2014) Class 1M Eye Safety
Horizontal Scan Range: 0°~360° Vertical Scanning Range: 0°~180°
Angular Resolution: 0.1° Pointing Accuracy: 0.1°
Maximum Location Update Rate: 2Hz Data Storage Time: 5 To 18 Months
Data Format: .csv File Environmental Adaptability And Reliability: -25~+50℃, Can Be Extended To -40~+60℃
Weight: ≤150kg GNSS Functionality: Support GPS/Beidou
Time Service: NTP Timing Or GPS/Beidou Timing
High Light:

Azimuth Running Wind Speed Lidar

,

Wind Speed Lidar OEM

,

Pitch Angular Velocity Wind Lidars

Angular velocity of pitch and azimuth running Wind Speed Lidar



1,Product introduction



Scanning mode: There are 4 scanning modes to choose from, namely: circular discrete, circular continuous, sector discrete, and sector continuous. The specific configuration methods are shown in Table 4 below;
Number of scan points: the number of sampling points for the running data of the scan configuration;
Angular velocity: the angular velocity of pitch and azimuth running;
Azimuth start: Azimuth scan start angle;
Azimuth rotation angle: Azimuth running angle value;
pitch start: pitch angle scan start angle;
Pitch rotation angle: the value of the pitch angle running angle;



2,Performance parameters



Basic parameters
Line-of-sight detection distance 10km (typical case)
Distance resolution 30m/45m/60m/75m optional
Accumulation time 0.5s/1s/2s/4s/8s optional
Radial wind speed measurement range -75~+75 m/s
Radial wind speed measurement accuracy 0.1m/s
Number of distance layers up to 300
Horizontal scan range 360° × n
Vertical scan range -10°~190°
Pointing accuracy 0.1°
Scanning method PPI , RHI , DBS , LOS and Program Scan
Real-time data output form Profibus DP/Modbus TCP/CAN optional
Telecommunication 1000BASE-TX or 4G remote access
Environmental parameters
Operating temperature and humidity -25~+50℃ (extendable to -40~+60℃),
5%~100% RH
IP protection class Housing IP54, core module IP66
Anticorrosion grade C4
Survival wind speed 70m/s (fixed by foot or by wire rope)
Working altitude ≤3500m
Other parameters
Running power consumption ≤1kW
Powered by 110VAC±20% or 220VAC±20%,
50Hz±10%
Size 800mm*650mm*11
30mm
Weight ≤150kg
Accessibility
GNSS functionality Support GPS/Beidou
Time service NTP timing or GPS/Beidou timing



3,Schematic diagram of 3D scanning Doppler wind Lidar
