CANopen Fieldbus DC 24V 3A Lidar Wind Profiler OEM ODM

Brand Name:	MOVELASER
Model Number:	Molas CL
MOQ:	1 set
Price:	Dollar 1W$+ （Price consultation customer service）
Delivery Time:	1-2 months
Payment Terms:	L/C, D/A, D/P, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Ranging Method:

1ToF

Detection Distance:

200m@90% Reflectivity/ 140m@10% Reflectivity

Range Resolution:

≤0.1m

Measurement Accuracy:

±0.2m

Repeated Measurement Accuracy:

±0.2m

Resistance To Ambient Light:

100Klux

Wavelength:

905nm

Repeat Frequency:

20KHz Per Channel

Laser Safety Level:

Class 1

Range Of Working Temperature:

-40℃~+60℃

Working Humidity Range:

0%~100% RH

Luminous Flux 1:

0°

Luminous Flux 3:

4.09°±0.2°

Real-time Data Products:

Device ID, Directly Measure Distance, Return Light Intensity, Data Valid Flag, System Status

Fieldbus:

Profibus DP / Modbus RTU / CANopen Three Fieldbus Protocols, And RS485 Communication Can Be Customized

Operating Power Consumption:

Within 60W

Supply Voltage And Maximum Current:

DC 24V, 3A

Size:

200×200×250mm

Packaging Details:

Air Box

Supply Ability:

200 set ，1 month

Highlight:

DC 24V 3A Lidar Wind Profiler

Lidar Wind Profiler OEM

CANopen Fieldbus lidar profiler

Product Description

Wind Lidar Supply voltage and maximum current DC 24V, 3A

1,Product introduction

MolasCL cables include power cables and communication cables, and the default length is 11m. However, according to the actual wiring requirements of different models, the cable length can be customized.

2,Technical Data Sheet

Ranging index
Ranging method	1ToF
Detection distance	200m@90% reflectivity/ 140m@10% reflectivity
Range resolution	≤0.1m
Measurement accuracy	±0.2m
Repeated measurement accuracy	±0.2m
Resistance to ambient light	100Klux
Optical index
Wavelength	905nm
Repeat frequency	20KHz per channel
Laser safety level	Class 1
Environmental adaptability
Range of working temperature	-40℃~+60℃
Survival temperature range	-45℃~+65℃
Working humidity range	0%~100% RH
Enclosure rating	IP65 (or according to specific needs)
Working acceleration range	-0.5g ～ 0.5g
Beam pointing
Luminous flux 1	0°
Luminous flux 2	2.05°±0.2°
Luminous flux 3	4.09°±0.2°
Output measurement results
Real-time data products	Device ID, directly measure distance, return light intensity, Data valid flag, system status
Fieldbus	Profibus DP / Modbus RTU / CANopen Three fieldbus protocols, and RS485 communication can be customized
Qther
Operating power consumption	Within 60W
Supply voltage and maximum current	DC 24V, 3A
Size	200×200×250mm
