Product Details:
Payment & Shipping Terms:
|
Measuring Range: | 30-300 Meters | Measure The Number Of Layers: | 12 |
---|---|---|---|
Wind Speed Accuracy: | 0.1m/s | Protection Class: | IP67 (complete Machine) |
Measuring Wind Speed Range: | 0~75m/s | Size: | 682mm X 520mm X 641mm |
Powered By: | 24V DC / 100~240V | Power: | 70W |
Weight: | <75kg | Range Of Working Temperature: | -40℃ ~ 50℃(with Over Temperature Protection) |
Operating Humidity Range: | 0% To 100% | Eye Safety: | Class 1M (EN60825-1) |
Sampling Rate: | 1Hz | Wind Direction Measurement Range: | 0~360° |
Sweep Cone Angle: | 28° | ||
High Light: | 50C Temp Floating Lidar System,-40C Temp Floating Lidar System,Horizontal Vertical Wind Speed Lidar |
Range of working temperature -40℃ ~ 50℃ Floating Lidar System
1,Product introduction
① Low cost: Whether it is used with monopile platforms or buoys, the price is much lower than the construction cost of offshore wind towers
② Large range: 40~300m, 12 custom levels
③ High accuracy: full life cycle, accuracy up to 0.1m/s and 1°
2,Product parameters
Powered by | 24V DC / 100~240V |
Power | 70W |
Size | 682mm x 520mm x 641mm |
Weight | <75kg |
Range of working temperature | -40℃ ~ 50℃(with over temperature protection) |
Operating humidity range | 0% to 100% |
Protection class | IP67 (complete machine) |
Eye safety | Class 1M (EN60825-1) |
Measuring distance | 30~300m |
Measurement layer | 12 |
Sampling rate | 1Hz |
Wind speed measurement accuracy | 0.1m/s |
Wind direction measurement accuracy | 1° |
Wind speed measurement range | 0~75m/s |
Wind direction measurement range | 0~360° |
Sweep cone angle | 28° |
Data output | Horizontal wind speed, vertical wind speed, wind direction Timestamp, GPS, temperature, humidity and pressure, statistics |
Data Format | ASCII |
Communication | Ethernet (100BASE-TX) 3G/4G WiFi, satellite communication (optional) |
3,Application scenarios
① Early detection of wind resources
② Offshore construction and operation and maintenance wind power monitoring
③ Prediction of wind power in offshore wind farms
