MOVELASER Floating Lidar System Beidou Satellite Communication

MOVELASER Floating Lidar System Beidou Satellite Communication

MOVELASER Floating Lidar System Beidou Satellite Communication

Brand Name:	MOVELASER
Model Number:	Molas B300M
MOQ:	1 set
Price:	Dollar 13W$+ （Price consultation customer service）
Delivery Time:	1-2 months
Payment Terms:	L/C, D/A, D/P, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Float Diameter:

5m

Height:

9.5m

Weight:

15 Tons

Net Buoyancy:

10 Tons

Anchorage Applicable Water Depth:

10m-250m DIN5683-II Mooring Chain

Electricity Supply:

The Device Can Run For 90 Days In The Absence Of Wind And Light Without Charging

Packaging Details:

Air Box

Supply Ability:

200 set ，1 month

Highlight:

MOVELASER Floating Lidar System

,

Floating Lidar System MOVELASER

,

Floating Lidar Beidou Satellite Communication

Product Description

Floating Lidar System Satellite communication: Beidou (2 sets)

Data transmission mode: Wifi, 4G, satellite (no 4G signal), status data is transmitted every 2h, and wind measurement data is transmitted every 24h.

**General parameters**
Powered by	24V DC / 100~240V
Power	70W
Size	682mm x 520mm x 641mm
Weight	<75kg
Range of working temperature	-40℃ ~ 50℃(with over temperature protection)
Operating humidity range	0% to 100%
Protection class	IP67 (complete machine)
Eye safety	Class 1M (EN60825-1)

**Measurement parameters**
Measuring distance	30~300m
Measurement layer	12
Sampling rate	1Hz
Wind speed measurement accuracy	0.1m/s
Wind direction measurement accuracy	1°
Wind speed measurement range	0~75m/s
Wind direction measurement range	0~360°
Sweep cone angle	28°

**Data parameter**
Data output	Horizontal wind speed, vertical wind speed, wind direction Timestamp, GPS, temperature, humidity and pressure, statistics
Data Format	ASCII
Communication	Ethernet (100BASE-TX) 3G/4G WiFi, satellite communication (optional)

Tags:

Floating Lidar System

floating lidar offshore wind 14m

Marine Grade Floating Lidar System
